imc SPARTAN-R (16 Slots)
![](/fileadmin/Public/Products/Measurement_Hardware/imc_SPARTAN/imc-SPARTAN-R.jpg)
![imc SPARTAN-R 19" Rackversion (3HE/84TE) mit 16 Slots für bis zu 128 analogen Eingängen](/fileadmin/Public/Products/Measurement_Hardware/imc_SPARTAN/imc-SPARTAN-R.jpg)
19" rack version housing (3HE/84TE) with 16 slots for up to 128 analog inputs
Measurements (WxHxD in mm):
426,7 x 133,35 x310
Without handles, feet
Weight: 8kg
Configuration
SPARTAN -2 / 4 / 6 / 8 | SPARTAN-R | |
---|---|---|
General | ||
Aggregate sampling rate | 400 kSps | |
max. channel sampling rate | 500 Sps / chan | |
Housing type | portable | 19" rack |
max. number of channels configurable | 32/64/96/128 | 128 |
configurable module slots (1 slot = 4 HP) | 4/8/12/16 | 16 |
Operating conditions | ||
Operating temp. range | ![]() | |
Extended temp. range (incl. condensation) | ![]() ![]() | |
Shock vibration rating | 30g pk (3 ms) | |
Connectivity | ||
Ethernet | 100 MBit | |
W-LAN (WiFi) | ![]() | |
Wireless GSM | ![]() | |
GPS connection port | ![]() | |
Display connection port | ![]() | |
Remote controlled main switch | ![]() | |
Programmable status feedback (LEDs) | ![]() | |
Data Storage | ||
CF card slot (Compact Flash) | ![]() | |
storage on PC / network drive | ![]() | |
IDE hard drive (internal) | ![]() | |
Stand Alone Capabilities | ||
PC independent complex trigger functionality | ![]() | |
onboard real-time data analysis (imc Online FAMOS) | ![]() | |
Autarkic PC-less operation, self start (timer, absolute time) | ![]() | |
Synchronization & Clock | ||
Master-Slave between different imc systems | ![]() | |
NTP network based synchronization | ![]() | |
via external GPS signal | ![]() | |
via IRIG-B & DCF-77 signal | ![]() | |
Pulse Counter and Process Control (Digital I/O) | ||
16 Bit digital in, 8 Bit digital out | ![]() | |
4 pulse counter (2 chan quadrature mode) | ![]() | |
Field Bus Extensions | ||
CAN | ![]() | |
CAN-FD | ![]() | |
LIN | ![]() | |
FlexRay | ![]() | |
J1587 | ![]() | |
XCPoE | ![]() | |
EtherCAT | ![]() | |
Modbus | ||
ARINC | ![]() | |
MVB-Bus Typ EMD | ![]() | |
MVB-Bus Typ ESD | ![]() | |
IPTCom | ![]() | |
Power Supply | ||
DC input 10V to 32V | ![]() | |
AC/DC adapter (110 to 230VAC) | ![]() | |
data integrity upon power fail | ![]() | |
UPS | ![]() | |
isolated power supply input | ![]() | |
Software | ||
imc REMOTE WebServer | ![]() |
Key: | ![]() | ![]() |
