Aerospace Testing

Ready for Take-off?

Aerospace Testing: Advancing Flight and Safety

Avionics testing ensures passenger safety and sustains the future of the aviation industry. Innovation and accuracy are imperative, as modern avionics systems rely on precise measurement data for practical and complex simulations. Aerospace testing validates components and evaluates performance through several approaches. Ground testing evaluates components in a controlled setting, while structural testing ensures durability. Flight testing confirms capabilities through real-world maneuvers, enhancing flight characteristics after simulation and ground phases.

  Highly accurate and reliable data acquisition

  Supporting virtually all sensors and interfaces

  Real time analysis, monitoring and data reduction

  In flight reconfigurable telemetry data stream

  All based around the IRIG 106 standards

Contact us regarding your project

Flight Test Solution Flyer

Flight Test Instrumentation (FTI)

Simplicity and Maximum Flexibility in Recording and Analyzing Aircraft Parameters

In aviation, flight test instrumentation is crucial for gathering essential measurement data and parameters required for certification by aviation authorities. Diverse technologies and tools decode and interpret data during flight trials, offering a detailed overview of an aircraft's performance.

Key components include the flight recorder, analog sensor data, switching states, field bus info, and communication protocols like ARINC 429, ARINC 664, or MIL-STD-1553B from the flight control system. The flight control system manages maneuverability and stability, with flight test instruments capture data on control surface configurations, response times, and flight dynamics. Engineers use these measurements to optimize performance and safety.

The flight recorder, often known as the "black box," meticulously captures various parameters, providing crucial insights into an aircraft's behavior. The flight data computer offers real-time measurements of atmospheric parameters, enhancing data precision for informed decisions during flight tests.

Aerospace ground equipment acts as an intermediary, enabling real-time communication, data stream monitoring, and seamless information exchange between the aircraft and ground operations. This facilitates reviewing and replicating flight maneuvers, enhancing test process flexibility and adaptability.

Measurement data can be stored within the flight test measurement system or on the flight test engineer's workstation, or transmitted directly to a ground station via IRIG 106 telemetry standards. Aerospace ground equipment includes a reception antenna for telemetry signals, a system for PCM data stream decoding, and the capability to route distinct measurement data to separate workstations. This integration enhances communication and monitoring, streamlining the flight testing process.

Learn more about flight test solutions

Test Stand and Rig Solutions

Customized with a high degree of adaptation

Structural analysis of components (e.g., airframes, wings, rotor blades, landing gear, actuators, motors). Strain and stress measurement and control for calibration, static, fatigue and endurance test beds. Strain measurements on composite materials Turbine engine test cell instrumentation. Integrated automated test stand control and alarm systems.

Hardware-in-the-Loop (HiL) solutions for nose-wheel steering

Hardware-in-the-Loop (HiL) solutions for nose-wheel steering, iron bird and ISTR rigs. Development testing of cargo loading systems. Integrated ATP test stands for production and quality control. Development test bed for high-lift systems. Pressure and temperature scanner interfaces for turbine engine test cells. Vibration monitoring hardware and software.

Your benefit - our goal

  • We sell complete solutions not only products
  • One-stop shop for efficient measurement solutions - throughout the whole testing cycle
  • Anti-aliasing of analog inputs
  • Decentralized and distributed measurement - effective, flexible and reliable
  • TEDS-capability for automated sensor integration
  • Synchronous and multi-channel data acquisition
  • Rapid and reliable measurement results with integrated hardware and software solutions
  • All imc systems are software-configurable
  • Broad support of bus data systems (ARINC-429, ASCB-D, CAN, RS422 etc.)
  • User-specific extensions
